DDR2-0.8-60pin Burn in Test Socket Ball Pin Pitch 0.8mm DDR DIMM
Contact resistance:30m oh MAX.at 10mA and 20mV MAX...
Test lifetime:15000 times
Pin Pitch:0.8mm
Working temperature:-55~175 degree
Part number:DDR2 60pin Burn in socket
Product description:DDR2-0.8-60pin Burn in Test Socket Ball Pin Pitch 0.8mm DDR DIMM DRAM for DDR manufac...
Test lifetime:15000 times
Pin Pitch:0.8mm
Working temperature:-55~175 degree
Part number:DDR2 60pin Burn in socket
Product description:DDR2-0.8-60pin Burn in Test Socket Ball Pin Pitch 0.8mm DDR DIMM DRAM for DDR manufac...
DDR2-0.8-60pin Burn in Test Socket Ball Pin Pitch 0.8mm DDR DIMM DRAM for DDR manufacturer
Specification :
a) DDR2 60pin Ball Pitch 0.8
b) working temperature:-55~175℃
c) Apply to Memory Chip of Sumsung , Hynix , Winbond , Micron etc
d) Socket material :PEI
e) Rated current : 1A
f) Contact resistance : 30m oh MAX.at 10mA and 20mV MAX(Start)
g) Test lifetime : 15000 times
Please leave us a message which size / datasheet of your chip , so we can send the proper socket , thanks a lot !
We're the original manufaturer , we can provide the lowest and competitive price , the shortest processing time is guaranteed ! ! !
