SSD NAND flash SM2256K Controller test solution for BGA152 132 88 pin Flash Memory 4 in 1 test PCB board IC size 12*18 or 14*18mm

This board adopt SM2256K controller , can support BGA152/132/88. mutiple packaging flash memory chip test , test sockets can interchange freely .

This test solution Can meanwhile solder the clamshell spring socket on the test board by screws surface way. the NAND flash package BGA152/132/88 4CE can be tested and read its good or not,its capacity,its ID and other information,the software also provide the OPEN card function( MPtool ),and other helpful function.

A.silicon motion (SMI SSD) controller Introduction

1.Features

• High performance flash memory controller with 4-CH/8-CH flash interface

• Supports PCIe Gen3 x4 NVMe 1.3 and SATA 6Gb/s

• End-to-end Data Path Protection

• Priority NANDXtend erro-correcting and data protection technology

• DRAM ECC and SRAM ECC

• The latest security protocols, including AES 256, Trusted Computing Group (TCG) and Opal full-drive encryption compliant

• Global wear-leveling to extend product life cycle

• Flexible flash memory configuration

• Enhanced ESD design

• Internal voltage detection circuitry

• Available in commercial and industrial grade

2.Flash Memory

• Support for up to 8-16 flash CE pins per channel

• Support for latest Samsung, Toshiba, SanDisk, Micron, Intel, SK Hynix MLC, TLC and SLC Flash

3.User Benefits

• High performance data transfer rate to/from flash card

• Excellent data integrity and product reliability

• Superior compatibility performance with over 200 popular consumer electronic devices and PCs

4.Applications

SATA and PCIe SSDs for client, enterprise, data center and embedded applications

B.SM2256K SSD TEST solution Introduction

Product name: SM2256K test NAND flash test solution

Host standards : SATA 6Gb/s (revision 3.1);

PCB Interface: for computer connect-SATA port,for NAND flash chip socket

ECC support : Configurable BCH ECC;

Voltage support : 3.3V

DRAM : Yes;

TCG/AES : Yes;

Applications : SATA and PCIe SSDs NAND flash test(BGA152 BGA132 BGA88 package)

C.Socket introduce:

Universal SM2256K controller PCB with DIP48 receptacle device,can support many popular SSD flash chips,such as BGA132 BGA152 BGA88

Good socket design can help you change the size limiter to meet different size Chip.Now BGA series have 12*18mm and 14*18mm
